The John Deere 3025E Compact Utility Tractor is a reliable and easy-to-operate machine designed for property maintenance, landscaping and light agricultural tasks. As part of the John Deere 3E Series, the 3025E focuses on practicality, durability and value while still delivering strong diesel performance and excellent manoeuvrability.

Powered by a dependable three-cylinder Yanmar diesel engine, the 3025E provides efficient fuel consumption and consistent torque for a variety of tasks such as mowing, loader work, material handling and operating rear implements. Its compact design, hydrostatic transmission and four-wheel drive capability allow it to perform demanding jobs while remaining easy to operate for both professional and private users.

---

Key Features

Reliable Yanmar Diesel Engine

The 3025E is powered by a 1.64 L three-cylinder Yanmar diesel engine producing approximately 24.4 hp (18.2 kW) at 2,400 rpm. The engine features direct fuel injection and liquid cooling for dependable performance and improved fuel efficiency.

Hydrostatic Transmission

The tractor uses a two-range hydrostatic transmission (HST) that provides smooth, infinitely variable speed control. Twin-Touch™ pedals allow easy forward and reverse direction changes, making the machine particularly suitable for loader work and manoeuvring around obstacles.

Standard Four-Wheel Drive

The 3025E features mechanical front-wheel drive (4WD) for improved traction and stability when operating on slopes, soft ground or uneven terrain. A rear differential lock further improves traction when additional pulling power is required.

Efficient Hydraulic System

The tractor uses an open-centre hydraulic system designed to power loaders and hydraulic attachments effectively.

Hydraulic performance includes:

• Steering hydraulics: 15 L/min

• Implement hydraulics: 20.2 L/min

• Total hydraulic flow: 35.2 L/min

This provides reliable hydraulic performance for common compact tractor attachments and implements.

Category 1 Three-Point Hitch

The rear linkage is a Category 1 three-point hitch with position control, offering a lift capacity of approximately 615 kg at 610 mm behind the link arms. This allows the tractor to operate many implements such as rotavators, sprayers, flail mowers and spreaders.

Independent Rear PTO

An independent 540 rpm rear PTO provides approximately 17–19 hp of PTO power, enabling the tractor to run a wide variety of PTO-driven equipment including rotary cutters, mowers and tillers.

Practical Operator Station

The 3025E is designed with a simple and comfortable operator platform that prioritises ease of use. Key features include:

• Adjustable seat with suspension

• Foldable Roll-Gard™ ROPS rollover protection

• Power steering for easy control

• Simple instrument display

• Optional cruise control for longer working sessions

These features make the tractor comfortable to operate during extended work periods.

Wide Range of Attachment Compatibility

The 3025E can be equipped with numerous attachments and implements, including:

• Front loaders such as the 300E loader

• Mid-mounted mower decks

• Rotary brooms and snow blowers

• Front blades

• Rear PTO implements including rotavators, flail mowers and spreaders

This versatility allows the tractor to handle a wide variety of property maintenance tasks throughout the year.

---

Ideal Applications

The John Deere 3025E Compact Utility Tractor is well suited for:

• Estate and property maintenance

• Landscaping and groundskeeping

• Turf and pasture management

• Loader work and material handling

• Small agricultural and horticultural operations

• Snow removal and seasonal maintenance

Its compact dimensions and versatile attachments make it ideal for both homeowners and professional users managing land or properties.

---

Product Specifications

• Product Type: Compact Utility Tractor

• Model: John Deere 3025E

• Series: John Deere 3E Series

• Engine Manufacturer: Yanmar

• Engine Type: 3-cylinder liquid-cooled diesel

• Engine Displacement: 1.64 L

• Engine Power: 24.4 hp (18.2 kW) at 2,400 rpm

• PTO Power: Approx. 17–19 hp

• Transmission: Two-range hydrostatic transmission (HST)

• Drive System: Mechanical front-wheel drive (4WD)

• Hydraulic System: Open-centre

• Total Hydraulic Flow: Approx. 35.2 L/min

• Rear Hitch Type: Category 1 three-point linkage

• Rear Lift Capacity: Approx. 615 kg at 610 mm behind link arms

• Fuel Tank Capacity: Approx. 28.5 L

• Wheelbase: Approx. 1,593 mm

• Shipping Weight: Approx. 1,007–1,181 kg depending on configuration

---

Why Choose the John Deere 3025E

The John Deere 3025E Compact Utility Tractor offers a straightforward and dependable solution for property owners and professionals who require a capable compact tractor without unnecessary complexity. Its reliable Yanmar diesel engine, hydrostatic transmission and four-wheel-drive system provide strong performance across a wide range of tasks.

With excellent attachment compatibility, simple controls and the durability expected from John Deere equipment, the 3025E provides an efficient and versatile tractor solution for landscaping, property maintenance and light agricultural work.
